Electrical characteristics
Nominal capacity 2400MAh
(At 23±2℃discharge at constant current 1mA until 2.0V cut off,Battery capacity depending on temperature ,discharge currents and cutoff voltage changes.)
Nominal voltage 3.6V
(Micro-current discharge platform voltage reference values has 3.0V to do with battery chemistry system and has nothing to do with the battery model. )
Maximum continuous current 100mA
(At 23±2℃ the battery can discharge at least the max continuous discharge value which rated capacity 50% can permit.)
Maximum pulse discharge current 200mA
(At 23±2℃,battery discharge duration for 3 seconds and stand 27 seconds, it can discharge at least the max pulse discharge value which rated capacity 50% can permit.)
Storage condition ≤30℃&≤75%RH
(Stored the battery under recommends condition to make sure effectively battery's performance, the storage temperature or humidity too high will increase battery's self-discharge rate and
reduce battery's storage life.)
Operating temperature - 55°C~+ 85°C
(Exceed the operating temperature range could lead to battery operating voltage reduction or even a security risk. )
Outline dimension Φ14.5×50.5mm
Weight 20g
Self-discharge rate 1%
(Out of the recommended condition, the self-discharge rate may increase.)
